Processing
thickness:
3~40mm
Dia:
100~2200mm
Max.width
of bevel:
35mm
Bevel
degree:
0°~45°
degree of vacuum should be reached: -0.08MPa~-0.1MPa
water
pressure: 0.1MPa~0.2MPa
Air
source pressure:
0.6MPA~0.8MPa
Rotating
speed of working table:
0.3rpm~3rpm
Rotating speed of independent turnplate: 0.7rpm~7rpm
Min.incurvature
radius:
R100mm
Max.rotating
radius:
1500mm
Height
of working table:
1100mm
Weight:
900KG
Power:
3.92KW
Size: 1100*1100*1800mm
